MSDS 3.2V 202Ah Lithium LiFePO4 Battery Deep Cycle For Solar Energy Pack
| Warranty:: | 5Year | LifeCycle:: | >6000times (100%DOD) |
| Battery Capacity:: | 202Ah | Voltage:: | 3.2v |
| Cell Size: | 52*174*201mm | Weight:: | 4.1KG |
| High Light: | 202Ah Lithium LiFePO4 Battery,MSDS Lithium LiFePO4 Battery,MSDS prismatic lifepo4 battery |
||
3.2V 202Ah LiFePo4 prismatic battery Deep Cycle for Solar battery pack LFP prismatic battery
Key Specifications/Special Features:
Nominal Voltage:3.2V
Nominal Capacity:202Ah
Battery Dimension:52*174*201mm
3.2V 202AH LiFePO4 Lithium Battery cell
• High lifespan: Six thousand cycles and more (see chart)
• Deep discharge allowed up to 100 %
• Ultra safe Lithium Iron Phosphate chemistry (no thermal run-away, no fire or explosion risks)
• Embedded BMS (Battery Management System) : improve lifespan AND secure the battery
• No Lead, no heavy metal, no toxic element • Calendar life > 10 years
• Excellent temperature robustness (-20 °C up to +60 °C)
• Flexible deployment : up to 10 packs in parallel and 4 in serial
• Constant power during discharge (very low internal resistance)
• Very low Peukert's losses (energy efficiency >96 %)
• Very low self discharge (<3 % per month)>
• No memory effect
• About 50% lighter and 40% smaller than equivalent Lead-AGM battery with same usable energy
• Certification : CE, RoHS,MSDS
| Nominal Voltage | 3.2V |
| Capacity | 202Ah |
| Core size | 52*174*201mm |
| Cell Weight | 4.1KG |
| Charging Current | Standard Charging:0.2C |
| Max Charging:1C | |
| Max Discharging Rate | Continuous Discharging:2C |
| Cut-off Voltage | Charging:3.65V |
| Discharging:2.5V | |
| Internal Resistance | ≤ 0.5m&OPurple Horn; (At 0.2C rate, 2.0V cut-off) |
| Working Temperature | Charging: -10°C~55°C |
| Discharging: -20°C~70°C | |
| Storage Temperature | ≤1month: -10–45°C |
| ≤3month: 0–30°C | |
| ≤6month: 20±5°C | |
| Life Cycle | >6000 times (100%D0D) |
