Name: IEC61233 standard 3.7V80mAh Lithium Ion Polymer Battery Smart Wearable Products
Brand: MEGA
SKU: 80mAh 3.7v Polymer Lithium Battery

Features Gallery Product Description Request A Quote

Features

Basic Infomation

Place of Origin: Fujian China

Brand Name: MEGA

Certification: CE, RoHS, REACH, UL, UN38.3 , IEC 62133

Model Number: 80mAh 3.7v Polymer Lithium Battery

High Light:

MEGA 3.7V80mAh Lithium Ion Polymer Battery

IEC61233 Lithium Ion Polymer Battery

IEC61233 3.7 v 80mah battery

Payment & Shipping Terms

Packaging Details: 600pc in a carton

Delivery Time: 3-5days

Payment Terms: L/C, T/T, Western Union,Credit Card.Paypal

Supply Ability: 1000000 Piece/Pieces per Month

Specifications

Capacity:: 80mAh

Size:: 3.5*15*30 MM

Cycle Life:: 500 Times

Voltage:: 3.7V

Weight: Approx3g

Warranty: 1 Years

Gallery

Product Description

Key Specifications/Special Features:

Advantages:
1. High energy density: volume energy density can be 460Wh/L
2. Excellent security: no fire, no explore of short-circuit, over-charge, over-discharge, over-current, Shock, vibration, crush, acupuncture.
3. Long cycle lifespan: capacity recovery can be above 80% after 500 cycles
4. High discharge voltage plateau: the 3.6V discharge voltage plateau is more than 42min
5. Environment-friendly: no PB, CD added
6.Flexible size design subject to different space of application
7. Hundreds of moulds for micro size with 10mAh-1000mAh
8. CE/RoHS Directive/REACH/UL/MSDS/UN38.3/IEC61233 standards

Applications:
Bluetooth earphone, smart watch, smart wearable, bank Ukey, POS device, medical equipment and other portable devices.

Trading details:
1) Packing: industrial packing (can be as customer's requirements)
2) Delivery lead time: usually 15-35 business days after payment
3) Payment term: T/T, Western Union, PayPal, L/C

Cells production process:
First from raw materials drying- mixing- coating -electrode drying- calendaring -cutting- punching- stacking- tab welding- short circuit checking- pre packing -electrolyte injection -pre formation- degassing gas -bag cutting -folding- code printing- formation -aging- finished products

Name	Lithium-ion polymer battery
Nominal voltage	3.7V
Nominal capacity	80mAh
Dimensions	(T) 3.2 * (W) 10* (H) 33mm
Standard charging current	0.2C
Standard discharging current	0.2C
Max charging current	1C
Max continuous discharging current	1C
Pulse discharging current	1.5C
Cut off voltage	3.0/4.2V
Cycle life	500 times
Charging temperature	0°C- 45°C
Discharging temperature	-20°C- 60°C
Storage temperature	-10°C- 45°C (recommend 20°C+/-5°C)
Appearance	without scratch, distortion, contamination and leakage
PCB	Optional
Wire	Optional
Connector	Optional
Certifications	CE, RoHS, REACH, UL, UN38.3 , IEC 62133
