Name |
Lifepo4 battery 12v 12.8v 100ah lithium ion battery supplier solar lithium batteries for RV/Marine/Solar /Golf cart/UPS/Camping |
||||
|
Function |
Same size with lead acid battery ,easy to replace old battery, lifepo4 battery for golf cart ,RV ,solver system |
||||
|
Modal |
TC1250 |
TC1280 |
TC12100 |
TC12150 |
TC12200 |
|
Electrical Characteristics |
|||||
|
Rated voltage |
12.8V |
12.8V |
12.8V |
12.8V |
12.8V |
|
Rated capacity |
50Ah@0.2C |
80Ah@0.2C |
100Ah@0.2C |
150Ah@0.2C |
200Ah@0.2C |
|
Rated power |
640Wh |
1024Wh |
1280Wh |
1920Wh |
2560Wh |
|
Internal Resistance |
60≤mΩ |
40≤mΩ |
40≤mΩ |
40≤mΩ |
30≤mΩ |
|
Cycle Life |
>2000 Cycles @ 0.2C Charge/Discharge at 100%DOD,End of Life 70% Capacity |
||||
|
Months Self Discharge |
≤3.5% per month at 25℃ |
||||
|
Standard Charge |
|||||
|
Charge Voltage |
14.6±0.2V |
14.6±0.2V |
14.6±0.2V |
14.6±0.2V |
14.6±0.2V |
|
Charge Mode(CC/CV) |
CC/CV |
CC/CV |
CC/CV |
CC/CV |
CC/CV |
|
Charging electricity |
10A |
20A |
20A |
30A |
40A |
|
Max charging electricity |
50A |
60A |
70A |
100A |
100A |
|
Standard Discharge |
|||||
|
Discharging electricity |
20A |
20A |
20A |
30A |
40A |
|
Max. Continuous electricity |
50A |
80A |
100A |
150A |
150A |
|
Max.Pulse Current |
120A(<3S) |
200A(<3S) |
250A(<3S) |
300A(<3S) |
300A(<3S) |
|
Discharge Cut-off Voltage |
10.8V |
10.8V |
10.8V |
10.8V |
10.8V |
|
Environmental |
|||||
|
Charge Temperature |
0℃~45℃ |
||||
|
Discharge Temperature |
-20℃~60℃ |
||||
|
Storage Temperature |
0℃~45℃ |
||||
|
Water Dust Resistance |
IP55 |
||||
|
Mechanical |
|||||
|
Plastic Case |
ABS |
||||
|
Dimension(L*W*H*TH) |
229x138x208mm |
256x165x208mm |
328x172x215mm |
483x170x240mm |
522x240x218mm |
|
Weight |
6Kg |
10Kg |
12.5Kg |
18Kg |
21Kg |
|
Terminal |
M6 |
M6 or M8 |
M8 |
M8 |
M8 |
12V High power LiFePO4 Battery Module with compact designed housing, built-in BMS as a key-turn and plug-and-play battery solution todirect drop in Replacement on typical lead-acid(AGM/GEL) battery applications.
Providing twice the run-time at approximately half the weight of a comparatively sized lead-acid battery, excellent float and cycle life over 3000times results in low operating costs with high investment returns for end user applications.
Q1. Can I have a sample order for lithium ion battery?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A:Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than
Q3. Do you have any MOQ limit for lithium battery?
A: Low MOQ, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for lithium ion battery?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6. Can we sign a secrecy agreement if we wanna build a long-term business relationship?
A: Sure, we respect clients requirements, will bring more benefit to you.
Q7: Do you offer guarantee for the products?
A: Yes, we offer 12 months warranty to our products.
Q8: Do you accept OEM/ODM?
A: Sure, the customized order is available, with our pleasure to serve on you.
Q9: How long does it take to recharge the battery?
A: usually it takes 5 hours with 20A standard charger.
