Nominal Voltage
|
51.2V
|
|
Charge Voltage
|
58.4V
|
|
Continuous Charge / Discharge Rate
|
100A
|
|
Capacity (amp hours)
|
100AH
|
|
Capacity (watts)
|
5120W
|
|
Chemistry
|
Lithium Iron Phosphate (LiFePO4)
|
|
Deep cycle life
|
2500 times, 85%dod,5000 times at 65%
|
|
Weight
|
99 lbs (45kg)
|
|
Size
|
415*430*175mm (16.5*17*7 inches) (L*W*H)
|
|
Usable Capacity (AH)
|
100AH
|
|
Depth of Discharge
|
100% DOD
|
|
Reserve Minutes @ 20A
|
300 min
|
|
Reserve Minutes @ 50A
|
120 min
|
|
Self Discharge
|
≤3% per mo
|
|
Chemistry
|
Lithium Iron Phosphate (LiFePO4)
|
|
Cell Type
|
Prismatic
|
|
Modular
|
Parallel Connection
|
|
Connector
|
M8 screw
|
|
Charge Temperature
|
0℃ to 45℃(32℉ to 113℉)
|
|
Discharge Temperature
|
-20℃ to 60℃(-4℉ to 140℉)
|
|
Storage Temperature
|
0℃ to 45℃(32℉ to 113℉)
|
|
Water Dust Resistance
|
IP56
|
|
Built in Automatic Battery Protection System
|
Yes
|
|
Automatic Low Voltage Disconnect
|
Yes
|
|
Automatic Short Circuit Protection
|
Yes
|
|
Automatic Over Voltage Protection
|
Yes
|
|
Automatic Over Current Protection
|
Yes
|
|
Automatic Internal Cell Balancing
|
Yes
|
|
Automatic Over Charge Protection
|
Yes
|
|
Automatic Over Discharge Protection
|
Yes
|
|
Automatic Over Temperature Protection
|
Yes
|
