103040 Basic Information |
Dimension( thickness*width*length) | 10*30*40(mm) |
| Charge voltage | 4.2V | |
| Nominal voltage | 3.7V | |
| Nominal capacity | 1200mAh | |
| Fully charge voltage | 4.2v | |
| Ship out volatge | 3.85-4.1v |
| Battery specification | Charge current | Standard Charging:0.5C (600mA) |
| Rapid charge:1.0C(1200mA) | ||
| Charging method | Charge with constant current 0.5c to 4.2V, then chagre with constant voltage 4.2v till until charge current is less than 0.01C | |
| Standard discharge current | 0.2C(240mA) | |
| Max.discharge current | 1C(1200mA) | |
| Discharge cut-off voltage | 3.0v | |
| Operating enviroment | Charging:10℃~45℃ | |
| Discharging:-10℃~60℃ | ||
| Storage temperature | -10℃~45℃ | |
| Cell Weight | Approx: 24g | |
| Battery recyle time | 500 times | |
| Warranty | 12 months |
